Supco Universal Refrigerator Relay & Overload Combo 1/2–2/3HP (RO22)

Supco Universal Refrigerator Relay & Overload Combo 1/2–2/3HP (RO22)

This Supco RO22 is a universal relay and overload combination for 240V refrigeration compressors from 1/2HP to 2/3HP. It replaces the separate start relay and overload fitted to many fridge and freezer compressors, and gives locked rotor protection to prevent start winding overheating.

It mounts with a snap on bracket and quick connect terminals, and can be used with or without a start capacitor. Check the compressor horsepower before fitting.

Features:

• Universal compressor relay and overload combination
• Suits 1/2HP to 2/3HP compressors
• 230V to 240V
• Locked rotor protection
• Snap on bracket with quick connect terminals
• Can be used with or without a start capacitor
• 7.5A full load, 22A trip current
